How much VRAM do you need to run an LLM locally? The simple math
A plain-English formula for working out how much GPU memory a local AI model needs, with worked examples for 8GB, 12GB, 16GB and 32GB cards.
Local AI hardware sizing sheet: VRAM calculator for running LLMs on RTX 50 cards
A spreadsheet and a Python script that work out how much VRAM a local model needs (weights plus KV cache) and which RTX 50 cards fit it. Card specs from NVIDIA, checked Oct 22, 2026.
Want to know if a model will run on your card before you download 20GB? This sheet does the arithmetic from How much VRAM do you need to run an LLM locally? for you.
Preview: vram_calc.py (core math)
GIB = 1024 ** 3
def weights_bytes(params_b, bits):
return params_b * 1e9 * bits / 8
def kv_bytes(layers, kv_heads, head_dim, tokens, kv_bits=16):
return 2 * layers * kv_heads * head_dim * (kv_bits / 8) * tokens
def fits(need_bytes, vram_gib, headroom):
return need_bytes <= vram_gib * GIB * headroom
Example: an 8B model at 4-bit with a 32k context, using the article's worked shape (32 layers, 8 KV heads, head size 128), needs about 3.7 GiB for weights and 4 GiB for the KV cache. That's too big for an 8GB card at 85% headroom, but fits a 12GB card.
What's inside
local-llm-vram-sizing.xlsx: the calculator, with an RTX 50 table that marks each card "fits" or "too big"vram_calc.py: the same math on the command line, with--configto read a model'sconfig.jsonrtx-50-vram.csv: VRAM, memory type, bandwidth and starting prices from NVIDIA, checked Oct 22, 2026model-weights-gb.csv: weight sizes for 8B to 120B models at 16, 8 and 4 bitstests/: unit tests for the formulas
How to use it
- Open the spreadsheet (or import it into Google Sheets).
- Fill in the yellow cells: parameters, bits, layers, KV heads, head size and context.
- If you know the real file size, enter it. It overrides the formula.
- Read the "Fits?" column.
Who it's for
Anyone choosing a GPU, or a model for the GPU they already have.
Related
FAQ
Where do I find layers, KV heads and head size?
In the model's config.json on its model page: num_hidden_layers, num_key_value_heads and head_dim. If head_dim is missing, it's hidden_size divided by num_attention_heads.
Why does the sheet say GiB?
GPU memory is counted in binary units (1 GiB = 1,073,741,824 bytes), so the sheet converts everything to GiB before comparing it with a card.
Does it work for Apple Silicon or AMD cards?
The math does. Put your memory size in the 'Your card' row (or use --vram) instead of reading the RTX 50 list. On a Mac, leave room for the system, since memory is shared.
Why does a model that 'fits' still run out of memory?
Real quantized files are often a bit bigger than the formula, and runtimes add their own buffers. Use the real file size and keep the headroom at 85–90%.
